Engine

The powerful and reliable Kubota built engine gets the job done quickly and easily with 64.0hp* (SSV65) or 74.3 hp* (SSV75). * Engine HP Gross (SAE J 1995). The Common Rail System (CRS) electronically controls the fuel injection timing and amount in stages rather than all at once for optimal combustion; resulting in greater efficiency, better fuel economy and less engine noise. The combination of Exhaust Gas Re-circulation (EGR) and Diesel Particulate Filter (DPF) reduces the emissions making the SSV Series engine Tier IV certified.

Kubota's Automatic Regeneration System burns away the soot that accumulates in the DPF muffler to keep the muffler clean and let you work longer. For safety, the automatic regeneration can be turned off when operating in fire-prone areas.

Engine

The powerful and reliable Kubota built engine gets the job done quickly and easily with 64.0hp* (SSV65) or 74.3 hp* (SSV75). * Engine HP Gross (SAE J 1995). The Common Rail System (CRS) electronically controls the fuel injection timing and amount in stages rather than all at once for optimal combustion; resulting in greater efficiency, better fuel economy and less engine noise. The combination of Exhaust Gas Re-circulation (EGR) and Diesel Particulate Filter (DPF) reduces the emissions making the SSV Series engine Tier IV certified.

Kubota's Automatic Regeneration System burns away the soot that accumulates in the DPF muffler to keep the muffler clean and let you work longer. For safety, the automatic regeneration can be turned off when operating in fire-prone areas.

Specifications

Download Brochure
Engine
Name SSV65 ISO SSV75 ISO
Engine Type Tier 4 Emission Level Tier 4 Emission Level
Fuel Type Diesel Diesel
Cylinders 4 4
Engine Model Kubota V2607-CR-TE4 Kubota V3307-CR-TE4
Engine Net 61.3 HP 71.6 HP
Engine Gross 64 HP 74.3 HP
Displacement 2,615 cc 3,331 cc
Rated speed 2,700 rpm 2,600 rpm
Name SSV65 ISO SSV75 ISO
Traction Force 3,329 kgf 3,853 kgf
Min. Ground Clearance 193 mm 207 mm
Name SSV65 ISO SSV75 ISO
Aux Hydraulic Flow - Standard 68 l/min 79 l/min
Aux Hydraulic Flow - High 106 l/min 115 l/min
Loader Hydraulic Pressure (Per cm2) 230 kgf 230 kgf
Name SSV65 ISO SSV75 ISO
ROC - 50% Tipping Load 885 kg 1,220 kg
Tipping Load 1,770 kg 2,440 kg
Breakout Force - Bucket 2,195 kg 2,669 kg
Breakout Force - Lift Arm 1,750 kg 2,200 kg
Lift Arm Path Vertical Vertical
Name SSV65 ISO SSV75 ISO
Low 11.1 km/h 11.9 km/h
High 17.8 km/h 19 km/h
Name SSV65 ISO SSV75 ISO
Length 2,700 mm 2,920 mm
Width 1,689 mm 1,823 mm
Height 2,029 mm 2,065 mm
Operating Weight - Cab 3,200 kg 3,820 kg
Operating Weight - Open Cab 3,220 kg 3,740 kg
Name SSV65 ISO SSV75 ISO
Fuel Reservoir 96 l 102 l
Hydraulic Tank 16 l 16 l
Name SSV65 ISO SSV75 ISO
Cab
Open Cab
Front sliding window
