Model Comparison
- 50 hp
- 50 hp
Product Features
Powered by a reliable, heavy-duty Kubota 51HP engine. Kubota’s Synchro Shuttle Transmission offers smooth operability and powerful agility. The hanging clutch and brake pedals deliver easy manoeuvrability when shifting. With 4 main shift speeds and 2 range-shift speeds (Hi/Lo), you have 8 forward and 8 reverse speeds to choose from giving you the versatility you need to maximise your productivity. MX5200 3-point hitch features telescopic lower link ends and stabilisers to allow easy attachment of a wide variety of Category I and II rear-mounted implements and enormous lift capacity. 4WD provides outstanding pulling power and traction in almost any working condition. Featuring a bevel gear front axle to deliver smooth and full-power transfer, plus greater all around manoeuvrability.
Diesel Engine
Kubota’s revolutionary centre direct injection system (E-CDIS) engines offer more durability, power and fuel efficiency. Turbocharged, inter-cooled and 4 valve per cylinder engine technology offers higher torque and incredible pulling power. The MX5200 offers 50.7 and 51.2 net engine horsepower. Our 5200 gear model delivers 45 PTO horsepower, giving you the power to work more efficiently. These tractors feature a built-in balancer that helps minimise vibration and noise.
| Name | MX5200D | MX5200HD |
|---|---|---|
| Fuel Type | Diesel | Diesel |
| Cylinders | 4 | 4 |
| Engine Model | Kubota V2403 | Kubota V2403 |
| Engine Gross | 50 hp | 50 hp |
| PTO | 44 hp | 42.5 hp |
| Displacement | 2,434 cc | 2,434 cc |
| Fuel Tank Capacity | 48 l | 48 l |
| Rated Speed | 2,700 rpm | 2,700 rpm |
| Name | MX5200D | MX5200HD |
|---|---|---|
| Transmission | Synchronized | Hydrostatic |
| Ranges | 2 Range | 3 Range |
| Gears | 8F | 8F |
| Drive Method | 4WD | 4WD |
| Brakes | Wet Disc | Wet Disc |
| PTO 540 | 2,700 rpm | 2,700 rpm |
| Name | MX5200D | MX5200HD |
|---|---|---|
| Hydraulic Pump Output | 35.8 l/min | 35.8 l/min |
| 3-Point Hitch | Category II | Category II |
| Rear Linkage Lift Capacity | 1,300 kg | 1,300 kg |
| Steering | Hydraulic Power Steering | Hydraulic Power Steering |
| Name | MX5200D | MX5200HD |
|---|---|---|
| AG | ||
| Industrial | ||
| Turf |
| Name | MX5200D | MX5200HD |
|---|---|---|
| Minimum Low Speed | 1.6 km/h | 0 km/h |
| Maximum High Speed | 25.9 km/h | 25.9 km/h |
| Name | MX5200D | MX5200HD |
|---|---|---|
| Length | 3,315 mm | 3,120 mm |
| Width | 1,770 mm | 1,770 mm |
| Height | 2,430 mm | 2,430 mm |
| Wheelbase | 1,895 mm | 1,895 mm |
| Ground Clearance | 385 mm | 405 mm |
| Turning Radius | 2.7 m | 2.7 m |
| Tractor Weight | 1,615 kg | 1,712 kg |
