L Series Tractors | Performance & Comfort

Model Comparison

30.4 hp
30.4 hp
35.9 hp
35.9 hp
43.8 hp
43.8 hp

Product Features

Engine

Indirect injection, 3 or 4-cylinder E-TVCS Kubota diesel engines generate enough horsepower to tackle the toughest jobs. Built to last, these workhorses delivers dynamic output and high torque, while significantly reducing vibration and noise with a built-in balancer.

Engine

Standard L Series tractors in Kubota Down To Earth

Down to Earth is Kubota's inhouse magazine, which takes a closer look at Kubota's wide range of product offerings and how Kubota customers are utilising and benefitting from them. Across Australia and New Zealand there are thousands of people, all using Kubota machines to assist with their daily lives, in their own way, in some amazing places. Down To Earth shares their stories, stories about the people who are living the Kubota lifestyle. They are the people who are working hard, playing hard, and living life to the fullest. Read their stories here and how they use their Standard L Series tractors.

Ongmac Story

DTE Issue 2

Specifications

Highlight differences

Download Brochure

Engine

Name	L3200D	L3200HD	L3800D	L3800HD	L4600D	L4600HD
Fuel Type	Diesel	Diesel	Diesel	Diesel	Diesel	Diesel
Cylinders	3	3	3	3	3	4
Engine Model	Kubota D1503	Kubota D1503	Kubota D1803	Kubota D1803	Kubota V2203	Kubota V2203
Engine Gross	30.4 hp	30.4 hp	35.9 hp	35.9 hp	43.8 hp	43.8 hp
PTO	26.7 hp	25.2 hp	31.5 hp	30 hp	38.3 hp	36.8 hp
Displacement	1,499 cc	1,499 cc	1,826 cc	1,826 cc	2,197 cc	2,197 cc
Fuel Tank Capacity	38 l	38 l	38 l	38 l	48 l	48 l
Rated Speed	2,800 rpm	2,800 rpm	2,700 rpm	2,700 rpm	2,700 rpm	2,700 rpm

Drive Train

Name	L3200D	L3200HD	L3800D	L3800HD	L4600D	L4600HD
Transmission	Mechanical	Hydrostatic	Mechanical	Hydrostatic	Synchronized	Hydrostatic
Ranges	2 Range	3 Range	2 Range	3 Range	2 Range	3 Range
Gears	8F	8F	8F	8F	8F	8F
Drive Method	4WD	4WD	4WD	4WD	4WD	4WD
Brakes	Wet Disc	Wet Disc	Wet Disc	Wet Disc	Wet Disc	Wet Disc
PTO 540	2,430 rpm	2,430 rpm	2,425 rpm	2,425 rpm	2,640 rpm	2,475 rpm

Hydraulics

Name	L3200D	L3200HD	L3800D	L3800HD	L4600D	L4600HD
Hydraulic Pump Output	24.7 l/min	24.7 l/min	23.9 l/min	23.9 l/min	29.4 l/min	29.4 l/min
3-Point Hitch	Category I	Category I	Category I	Category I	Category I	Category I
Rear Linkage Lift Capacity	906 kg	906 kg	906 kg	906 kg	1,300 kg	1,300 kg
Steering	Hydraulic Power Steering	Hydraulic Power Steering	Hydraulic Power Steering	Hydraulic Power Steering	Hydraulic Power Steering	Hydraulic Power Steering

Tyre Options

Name	L3200D	L3200HD	L3800D	L3800HD	L4600D	L4600HD
AG
Industrial
Turf

Travelling Speeds

Name	L3200D	L3200HD	L3800D	L3800HD	L4600D	L4600HD
Minimum Low Speed	1.8 km/h	6.3 km/h	1.7 km/h	6.3 km/h	2.2 km/h	5.9 km/h
Maximum High Speed	22 km/h	23.6 km/h	21.2 km/h	22.7 km/h	24 km/h	25.4 km/h

Dimensions

Name	L3200D	L3200HD	L3800D	L3800HD	L4600D	L4600HD
Length	2,800 mm	2,800 mm	2,800 mm	2,800 mm	2,995 mm	2,995 mm
Width	1,400 mm	1,400 mm	1,400 mm	1,400 mm	1,585 mm	1,585 mm
Height	2,330 mm	2,330 mm	2,330 mm	2,330 mm	2,330 mm	2,330 mm
Wheelbase	1,610 mm	1,610 mm	1,610 mm	1,610 mm	1,845 mm	1,845 mm
Ground Clearance	340 mm	340 mm	340 mm	340 mm	385 mm	385 mm
Turning Radius	2.5 m	2.5 m	2.5 m	2.5 m	2.6 m	2.6 m
Tractor Weight	1,180 kg	1,190 kg	1,205 kg	1,210 kg	1,430 kg	1,450 kg
