SQ3140/SQ3200/SQ3300 Generator
Model Comparison
- 24.8 hours
- 25 hours
- 24 hours
Product Features
Engines
The Kubota SQ-3140B-AU-B is a premium compact three-phase four pole diesel generator with a capacity of 14kVA at 1500RPM and is available to work under a single phase 240 voltage and run a current (A) of 12.5 amps or a 3 phase 415 voltage and a run a current of 19.5 amps per phase. Powered by Kubota’s D1703 fuel efficient, water cooled diesel engine.
The Kubota SQ-3200B-AU-B is a premium compact three-phase four pole diesel generator with a capacity of 20kVA at 1500RPM and is available to work under a single phase 240 voltage and run a current (A) of 18.1 amps or a 3 phase 415 voltage and a run a current of 27.8 amps per phase. Powered by Kubota’s renowned V2203 water cooled diesel engine.
The Kubota SQ-3300B-AU-B is a premium compact three-phase four pole diesel generator with a capacity of 30kVA at 1500RPM and is available to work under a single phase 240 voltage and run a current (A) of 27.1 amps or a 3 phase 415 voltage and a run a current of 41.7 amps per phase. Powered by Kubota’s extra reliable V3300 water cooled diesel engine.
Kubota diesel engines incorporate a TVCS combustion system which improve air/fuel mixture, resulting in cleaner emissions. All models are available with automatic shutdown of the engine if abnormal conditions are detected.
| Name | SQ3140B | SQ3200B | SQ3300B |
|---|---|---|---|
| Fuel Type | Diesel | Diesel | Diesel |
| Phase | Three | Three | Three |
| Fuel Tank Capacity | 72 l | 100 l | 142 l |
| Operating Hours @Full Load | 24.8 hours | 25 hours | 24 hours |
| Starting System | Electric | Electric | Electric |
| Weight | 780 kg | 915 kg | 1,135 kg |
| Sound Levels @7m | 61 dBA | 63 dBA | 64 dBA |
| Dimensions | 1725 x 795 x 1095 mm | 1725 x 795 x 1180 mm | 1935 x 860 x 1310 mm |
| Name | SQ3140B | SQ3200B | SQ3300B |
|---|---|---|---|
| Engine Model | D1703-EBG | V2203-EBG | V3300-EBG |
| Engine Type | Vetical Water Cooled | Vertical Water Cooled | Vertical Water Cooled |
| Displacement | 1,647 cc | 1,647 cc | 3,318 cc |
| No of Cylinders | 3 | 4 | 4 |
| Bore & Stroke | 87 x 92.4 mm | 87 x 92.4 mm | 98 x 110 mm |
| Rated Output | 13.6 kW (18.2 hp) | 18.4 kW (24.7 hp) | 26.8 kw (35.9 hp) |
| RPM | 1,500 rpm | 1,500 rpm | 1,500 rpm |
| Name | SQ3140B | SQ3200B | SQ3300B |
|---|---|---|---|
| Type | Revolving Field | Revolving Field | Revolving Field |
| Max Output | 15.4 kVA | 22 kVA | 33 kVA |
| Rated Output | 14 kVA | 20 kVA | 30 kVA |
| Voltage | 240/415 | 240/415 | 240/415 |
| Frequently | 50 Hz | 50 Hz | 50 Hz |
| Current | 19.5 Amps | 27.8 Amps | 41.7 Amps |
| Power Factor | 0.8 | 0.8 | 0.8 |
| Poles | 4 | 4 | 4 |
| Voltage Regulation | AVR | AVR | AVR |
