ActiveMow R Rear Mounted Disc Mowers

Model Comparison Product Features Specifications
ActiveMow R Rear Mounted Disc Mowers previewActiveMow R Rear Mounted Disc Mowers
Krone ActiveMow mowers set the benchmark for lateral mowers, bringing the features of larger commercial mowers in a package suitable for smaller operators. The AM R Mower range features the same specifications as Krone's high-end mowers, including SmartCut cutterbars and massive headstocks. ActiveMow mowers are available in a range of models, with a working width between 2.44 and 3.61 metres. All offer exceptional quality and value for years of dependable use.

Model Comparison

Finance Offers
Download Brochure
  • 2,440 mm
  • 2,830 mm
  • 3,220 mm
  • 3,610 mm

Product Features

kubota previewkubota
1
2
3
4
5

SafeCut

In the event of a collision, the roll pin that connects each disc to the gear is sheared off. This raises the affected disc up on a thread and out of the way, preventing the disc from being lost. SafeCut prevents damaged discs from colliding with neighbouring discs, preventing spur gear damage. Roll pins can be easily and cheaply replaced in just a few minutes.

SafeCut

In the event of a collision, the roll pin that connects each disc to the gear is sheared off. This raises the affected disc up on a thread and out of the way, preventing the disc from being lost. SafeCut prevents damaged discs from colliding with neighbouring discs, preventing spur gear damage. Roll pins can be easily and cheaply replaced in just a few minutes.

Specifications

Download Brochure
Dimensions & Weight
Name AMR240 AMR280 AMR320 AMR360
Working Width 2,440 mm 2,830 mm 3,220 mm 3,610 mm
Weight 550 kg 605 kg 650 kg 740 kg
Name AMR240 AMR280 AMR320 AMR360
PTO Min. 41 hp 55 hp 68 hp 75 hp
Discs 4 5 6 7
Drums 2 2 2 2
Rotation Direction B B B B
PTO Standard Speed 540 rpm 540 rpm 540 rpm 540 rpm
Three-point Hitch Cat. I and Cat. II Cat. I and Cat. II Cat. I and Cat. II Cat. I and Cat. II
Hydraulic Spools 1 SA 1 SA 1 SA 1 SA
Work Rate Min. 2 ha/h 2.5 ha/h 3 ha/h 3.5 ha/h
Work Rate Max. 2.5 ha/h 3 ha/h 3.5 ha/h 4 ha/h
Name AMR240 AMR280 AMR320 AMR360
SafeCut (shear pin disc impact protection)
SmartCut (optimised overlapon discs and satellite gear system)
One Piece Fully Welded Cutterbar (lifetime oil filling)
Krone Cutterbar Satellite System
Folding for Transport 100° Over Centre 100° Over Centre 100° Over Centre 100° Over Centre
Adjustable Mower Spring Suspension
PTO Shaft with Slip Clutch 2 Plate 2 Plate 2 Plate 2 Plate
Removable Blade Box
Brakeback System
Cast Wear Protection Points Between Discs
Direct Drive to Cutter Bar
Name AMR240 AMR280 AMR320 AMR360
Quick Change Blades
Right Swath Plate
Folding Side Guard
