M7-2 Standard
Model Comparison
- 128 hp
- 148 hp
- 168 hp
Product Features
The M7-2 is powered by a next-generation 6.1 litre, four-cylinder diesel engine, incorporating Kubota’s clean-air technology. 30 speed semi-powershift lets you find the right gear for every task. Some jobs can’t be done properly at typical working speeds and that’s why the M7-2 gives you additional 24 forward and 12 reverse creep speeds to let you do those jobs at extremely slow working speeds. The M7-2 standard model is ready to go to work with Pressure Compensated, Fixed Displacement hydraulics, a 80 l/min gear type pump and three mechanically controlled auxiliary valves as standard equipment and the option of adding a fourth auxiliary control valve.
Engine
The M7-2 Series includes Kubota's most powerful engine. Offering improved engine performance by lowering the rated engine speed from 2200 rpm to 2100 rpm and lowering the output speed from 2200 rpm to 1900 rpm. Kubota's updated engine results in better fuel economy and reduced engine noise. The M7-2 Series provides constant power and torque used for PTO and towing work.
M7-2 Standard in Kubota Down To Earth
Down to Earth is Kubota's inhouse magazine, which takes a closer look at Kubota's wide range of product offerings and how Kubota customers are utilising and benefitting from them. Across Australia and New Zealand there are thousands of people, all using Kubota machines to assist with their daily lives, in their own way, in some amazing places. Down To Earth shares their stories, stories about the people who are living the Kubota lifestyle. They are the people who are working hard, playing hard, and living life to the fullest. Read their stories here and how they use their M7-2 Standard.
| Name | M7-132 Standard | M7-152 Standard | M7-172 Standard |
|---|---|---|---|
| Fuel Type | Diesel | Diesel | Diesel |
| Cylinders | 4 | 4 | 4 |
| Engine Model | Kubota V6108 | Kubota V6108 | Kubota V6108 |
| Engine Gross | 128 hp | 148 hp | 168 hp |
| PTO | 102 hp | 122 hp | 142 hp |
| Displacement | 6,124 cc | 6,124 cc | 6,124 cc |
| Fuel Tank Capacity | 330 l | 330 l | 330 l |
| Rated Speed | 1,900 rpm | 1,900 rpm | 1,900 rpm |
| Name | M7-132 Standard | M7-152 Standard | M7-172 Standard |
|---|---|---|---|
| Transmission | Semi-Powershift | Semi-Powershift | Semi-Powershift |
| Ranges | 5 Range | 5 Range | 5 Range |
| Gears | 30F | 30F | 30F |
| Drive Method | 4WD | 4WD | 4WD |
| Brakes | Wet Disc | Wet Disc | Wet Disc |
| PTO 540 | 1,000 rpm | 1,000 rpm | 1,000 rpm |
| Name | M7-132 Standard | M7-152 Standard | M7-172 Standard |
|---|---|---|---|
| Hydraulic Pump Output | 80 l/min | 80 l/min | 80 l/min |
| 3-Point Hitch | Category III | Category III | Category III |
| Rear Linkage Lift Capacity | 9,400 kg | 9,400 kg | 9,400 kg |
| Steering | Hydraulic Power Steering | Hydraulic Power Steering | Hydraulic Power Steering |
| Name | M7-132 Standard | M7-152 Standard | M7-172 Standard |
|---|---|---|---|
| AG |
| Name | M7-132 Standard | M7-152 Standard | M7-172 Standard |
|---|---|---|---|
| Minimum Low Speed | 0.37 km/h | 0.37 km/h | 0.37 km/h |
| Maximum High Speed | 40 km/h | 40 km/h | 40 km/h |
| Name | M7-132 Standard | M7-152 Standard | M7-172 Standard |
|---|---|---|---|
| Length | 4,770 mm | 4,770 mm | 4,770 mm |
| Width | 2,500 mm | 2,500 mm | 2,500 mm |
| Height | 3,010 mm | 3,010 mm | 3,010 mm |
| Wheelbase | 2,720 mm | 2,720 mm | 2,720 mm |
| Ground Clearance | 410 mm | 410 mm | 410 mm |
| Turning Radius | 6.35 m | 6.35 m | 6.35 m |
| Tractor Weight | 6,730 kg | 6,730 kg | 6,730 kg |
